ELB Series Stainless Steel Plunger Pump Motor Set
Home » PRODUCTS » Plunger Pump Set/System » Electric Plunger Pump Set/System » ELB Series Stainless Steel Plunger Pump Motor Set
ELB Series Stainless Steel Plunger Pump Motor Set

loading

ELB Series Stainless Steel Plunger Pump Motor Set ELB Series Stainless Steel Plunger Pump Motor Set

ELB Series Stainless Steel Plunger Pump Motor Set

Availability:
Quantity:
  • ELB

  • BOTUO

Product Description

Excellent pump with suitable flow and pressure, you can use it for car washing and spraying. With the help of regulator valve, you could control the pressure by yourself. Stainless steel pump head and cast iron crank box make pump durable, stainless steel is suitable for desalination. The checking valve and ceramic plunger inside of pump are easily detached and have good performance. The crank shaft of pump is made by excellent alloy, it is strong and owns long use life. You can observe capacity of oil by oil mirror. When you first use our pump,you should change oil after using the pump for 50hours. Then you should change oil after pump being used 500hours. We will offer after-sale service within 1 year and offer service of providing spare part package.


Product Characteristic

1.Supper-alloy crank box and crank shaft

2.Special flange for connecting motor

3.Stainless steel pump head

4.Functional checking valve

5.Durable connecting rob

6.A pump specialize in sea water


Date Sheet
Pump ModelELB
Shaft & FlangeHallow 28mm
Plunger Diameter18mm
Stroke14mm
Max Input Power3kw
Max Input RPM1450rpm
Voltage & HZCustomize
Max Pressure100bar
Max Flow15lpm
Weight60kg
Application

Pharmaceutical Chemical Industr

Sea Water Desalination

Corrosive Fluid/Liquid


ModelMax Flow
Max Pressure
PowerRpm
L/mingpmBarpsihpkwrpm
ELB031030.79100145010.751450
ELB06105.51.45100145021.51450
ELB08107.51.98100145021.51450
ELB1210112.91100145032.21450
ELB1510153.961001450431450
