Excellent pump with Max 142L/min flow rate and 200 Bar pressure, you can use it for car washing and spraying. With the help of regulator valve, you could control the pressure by yourself. Cast iron pump head and crank box make pump durable and strong. The checking valve and ceramic plunger inside of pump are easily detached and have good performance. The crank shaft of pump is made by excellent alloy, it is strong and owns long use life. You can observe capacity of oil by oil mirror. When you first use our pump, you should change oil after using the pump for 50 hours. Then you should change oil after pump being used 500 hours. We will offer after-sale service within 1 year and offer service of providing spare part package.
Excellent pump with Max 142L/min flow rate and 200 Bar pressure, you can use it for car washing and spraying. With the help of regulator valve, you could control the pressure by yourself. Cast iron pump head and crank box make pump durable and strong. The checking valve and ceramic plunger inside of pump are easily detached and have good performance. The crank shaft of pump is made by excellent alloy, it is strong and owns long use life. You can observe capacity of oil by oil mirror. When you first use our pump, you should change oil after using the pump for 50 hours. Then you should change oil after pump being used 500 hours. We will offer after-sale service within 1 year and offer service of providing spare part package.
1. Supper-alloy crank box and crank shaft
2. Special flange for connecting motor
3. Cast iron pump head
4. Functional checking valve
5. Durable connecting rob
6. A pump specialize in industry
1. Supper-alloy crank box and crank shaft
2. Special flange for connecting motor
3. Cast iron pump head
4. Functional checking valve
5. Durable connecting rob
6. A pump specialize in industry
| Pump Model | GT |
| Shaft & Flange | N 30mm |
| Max Input Power | 28kw/38hp |
| Max Input RPM | 1750rpm |
| Max Pressure | 200bar/290psi |
| Max Flow | 142Lpm/37.5Gpm |
| Weight | 44kg |
| Application | High Pressure Water |
Model | Flow Rate | Pressure | Rpm | Power | ||||
L/min | gpm | bar | psi | Mpa | r.p.m | hp | kW | |
GT28 | 70.00 | 18.4 | 200 | 2900 | 20 | 1450 | 37 | 27 |
84.00 | 22.2 | 175 | 2538 | 17.5 | 1750 | 38 | 28 | |
GT30 | 80.00 | 21.1 | 175 | 2538 | 17.5 | 1450 | 38 | 28 |
96.00 | 25.5 | 140 | 2030 | 14 | 1750 | 37 | 27 | |
GT32 | 91.00 | 24.0 | 150 | 2175 | 15 | 1450 | 37 | 27 |
GT36 | 115.00 | 30.4 | 120 | 1740 | 12 | 1450 | 38 | 28 |
139.00 | 36.7 | 100 | 1450 | 10 | 1750 | 38 | 28 | |
GT40 | 142.00 | 37.5 | 100 | 1450 | 10 | 1450 | 38 | 28 |
GT45 | 124.00 | 32.8 | 100 | 1450 | 10 | 1000 | 33 | 24 |
112.00 | 29.6 | 100 | 1450 | 10 | 900 | 30 | 22 | |
99.00 | 26.2 | 100 | 1450 | 10 | 800 | 27 | 20 | |
