LT
BOTUO
Excellent pump with suitable flow and pressure, you can use it for car washing and spraying. With the help of regulator valve, you could control the pressure by yourself. Stainless steel pump head and cast iron crank box make pump durable, stainless steel is suitable for desalination. The checking valve and ceramic plunger inside of pump are easily detached and have good performance. The crank shaft of pump is made by excellent alloy, it is strong and owns long use life. You can observe capacity of oil by oil mirror. When you first use our pump, you should change oil after using the pump for 50hours. Then you should change oil after pump being used 500hours. We will offer after-sale service within 1 year and offer service of providing spare part package.
Excellent pump with suitable flow and pressure, you can use it for car washing and spraying. With the help of regulator valve, you could control the pressure by yourself. Stainless steel pump head and cast iron crank box make pump durable, stainless steel is suitable for desalination. The checking valve and ceramic plunger inside of pump are easily detached and have good performance. The crank shaft of pump is made by excellent alloy, it is strong and owns long use life. You can observe capacity of oil by oil mirror. When you first use our pump, you should change oil after using the pump for 50hours. Then you should change oil after pump being used 500hours. We will offer after-sale service within 1 year and offer service of providing spare part package.
1.Supper-alloy crank box and crank shaft
2.Special flange for connecting motor
3.Stainless steel pump head
4.Functional checking valve
5.Durable connecting rob
6.A pump specialize in sea water
1.Supper-alloy crank box and crank shaft
2.Special flange for connecting motor
3.Stainless steel pump head
4.Functional checking valve
5.Durable connecting rob
6.A pump specialize in sea water
| Pump Model | LT |
| Shaft Details | Solid & Hallow |
| Plunger Diameter | 25mm |
| Stroke | 14mm |
| Max Input Power | 5.5kw |
| Max Input RPM | 1450rpm |
| Max Pressure | 100bar |
| Max Flow | 30lpm |
| Weight | 11kg |
| Application | Pharmaceutical Chemical Industr Sea Water Desalination Corrosive Fluid/Liquid |
LT Series Parameters
| Model | Max Flow | Max Pressure | Power | Speed | |||
| L/min | gpm | bar | psi | hp | kW | r.p.m | |
| LT1610 | 16 | 4.23 | 100 | 1450 | 4 | 3 | 1450 |
| LT2310 | 23 | 6.08 | 100 | 1450 | 5.5 | 4 | 1450 |
| LT3010 | 30 | 7.93 | 100 | 1450 | 7.5 | 5.5 | 1450 |
| Pump Model | LT |
| Shaft Details | Solid & Hallow |
| Plunger Diameter | 25mm |
| Stroke | 14mm |
| Max Input Power | 5.5kw |
| Max Input RPM | 1450rpm |
| Max Pressure | 100bar |
| Max Flow | 30lpm |
| Weight | 11kg |
| Application | Pharmaceutical Chemical Industr Sea Water Desalination Corrosive Fluid/Liquid |
LT Series Parameters
| Model | Max Flow | Max Pressure | Power | Speed | |||
| L/min | gpm | bar | psi | hp | kW | r.p.m | |
| LT1610 | 16 | 4.23 | 100 | 1450 | 4 | 3 | 1450 |
| LT2310 | 23 | 6.08 | 100 | 1450 | 5.5 | 4 | 1450 |
| LT3010 | 30 | 7.93 | 100 | 1450 | 7.5 | 5.5 | 1450 |
